We start with only the finest quality!  Fine or precision annealed low



expansion borosilicate glass substrate, Schott Supremax 33,



unless otherwise noted. Each substrate is tested under polarized

light for internal strain and striae. No work will commence on any

substrate unless it passes this test, including optics sent to us for



re-figuring.  All of our substrates are free of any edge chips.



After diamond generation, fine grinding, polishing, and figuring, each



optic receives several hours of testing in our atmospherically


controlled shop. We use not one, but several precise optical tests.



The results from each test are cross-checked against each other in



order to provide an accurate qualitative and quantitative assessment



of the optical quality.





Our testing methods include.




*Foucault-Null Test: Used to obtain a reading of the overall

correction and to inspect the optical surface for smoothness. The



overall correction reading provided by this test is verified against



results obtained from Interferometry. In most cases we use a double-



pass null test.




*Figure of Revolution Test: Used for detecting stress induced flexure

errors and astigmatism. The primary mirrors manufactured at

Ostahowski Optics, Inc. are tested in the horizontal optical axis using



an optical mounting sling. The most common and severe stress



flexure aberrations are astigmatism and trefoil. Each optic receives



extensive testing to determine if the optical surface is exhibiting



stress flexure or true astigmatism. The astigmatic error that is not



induced by mounting stress is always removed during optical



figuring. Every primary must pass this surface of revolution test.



*Interferometric Testing: Interferometric testing is the standard that

aerospace industry, professional optical labs, government labs, and



well informed consumers, use for a quantitative assessment of the



optical wave front quality. Interferometry is a time consuming and



expensive process requiring a high degree of technical expertise. It



produces accurate test results enabling us to consistently produce



outstanding mirrors. This is the final test that all Ostahowski Optics,



Inc.. mirrors undergo and must pass.





We employ several different types of interferometers, each



has a specific use depending upon the optic, or system. During



interferometric testing the shape of an optic's wave front is

determined by superimposing its wave front over a reference wave

front that is certified to be highly accurate. Constructive and

destructive interference created between the superimposed wave

fronts generate the interference fringes. A CCD camera is then used



to capture an image of the interference fringes and send it to a



computer. Interferometric fringe analysis software is then used to



analyze the data points along the fringes and accurately determine



the deviation between the two wave fronts. Interferogram averaging



minimizes the effects of any air currents that may be in the light



path during testing providing accurate information about the true

wave front quality. The fringe analysis software then generates us a



detailed report. Mirrors certified by zonal Foucault test rarely attain



the same quality of results when tested by an interferometer and

almost always overstate the quality of the mirror being tested.




Test Data Provided

Ostahowski Optics, Inc. test data reports contain the following

information:

                        Interferogram


                        Strehl Ratio (primary optics and optical systems)

                        RMS Wave front Error

                        Peak to Valley Wave front Error

                        Wave front Map

The Process

Bad Anneal

Good Anneal

Generation

Fine grind inspection

Polishing

After polish Inspection

Surface of revolution

Interferogram

Hartmann Screen

Phase map
